Rating:100mA 12VDC
Dielectric? voltage:250VAC For1 Minute
Contact Resistance:200mΩ Max.(initial)
Insulation Resistance:100mΩMin
Operating Force:r 250±100gf
Total Travel:4.5±0.2mm
Operatong Life:1,000,000 Cycles Min
Solder specifications:260ofor5 seconds
Operating Temerature:-20℃~+70℃
