Rating:0.4VA/28VAC
Dielectric voltage:500VAC For1 Minute
Contact Resistance:100mΩ Max.(initial)
Insulation Resistance:DC500V 100mΩMin
Operating Force:r 200±100gl
Total Travel:2.2±0.15mm
Operatong Life:200,000 Cycles Min
Solder specifications:260ofor5 seconds
Operating Temerature:-25℃~+70℃
